The revolutionary dolly track system with a removable,
replaceable PVC plastic capped smooth riding surface.
Designed by both a Key Grip and Dolly Grip.
Film technicians, camera operators and Directors of
Photography appreciate G I track for the design,
features and quality components.




G I track Video
»Play Video*
*Requires quicktime.

Weight
8 foot section
- 40 lbs.
4 foot section
- 22 lbs.
2 foot section
- 15 lbs.

Rental Information
*Requires Acrobat Reader which is a free download from www.Adobe.com

Rental Information
for sales information and pricing contact Gillard Industries at Contact Us.

G I track Features


Features:


Patented extruded 6005AT61 structural aluminum rails and PVC plastic capping form together for the ultimate smooth tracking surface. Over time other manufactured precision track develop nicks and bumps and the rails become unusable. With the G I track PVC cap system, this is no longer a problem. If the cap gets damaged, simply replace it at a fraction of the cost.


G I track's (I beam construction) sections come complete with PVC capping. Aluminum rails are anodized black to minimize reflections and are available in 8, 4 and 2 foot sections. Cross member ties can be custom made for various dolly or crane track widths.


Scissored 8' section for storage. ( 10' L x 6" W x 3" H and weighs 40 lb.)


Patented extruded PVC plastic capping available in 2, 4, 8 and 16 foot lengths.

Offsetting the plastic capping 2” from the track
connections provides a smooth, seamless join.

Stainless steel male and female ends ensure a positive and durable connection.

Knurled nut tension adjuster on latch for connecting track sections together.

Cross member ties are fastened (a) vertically and (b) horizontally (two axis) to rails for added strength and rigidity. Ties can be custom made for different track widths to accommodate various camera dolly and crane tracking wheel configurations.

The design of (two axis) mounted cross member tie allows wedges to be cribbed only from the inside making a clear path on the outside rails of the track.

Long length track setups require minimal cribbing. Picture illustrates support cribbing and wedges required only at joins and midsection of track.

Latches are mounted on the outside of G I tracks rails ensuring a positive (in line) connection instead of the traditional method of latches mounted on the cross member ties. Latches that are out of the way allow the dolly grip and camera assistant the ability to walk either on cross member ties or along side the track free from obstruction. Cables no longer get hung up on latch handles.

Latch in storage position. A no tripping hazard at end of track set up.

Strong cross member ties for walking boards.

Screw holes for fastening to support timber.

All components are interchangeable, replaceable and made from nonferrous materials for all weather conditions. (Note: this excludes manufactured latch)
Track sections have there own serial numbers for identification and web address for customer support.

CNC machined components for consistency and trueness

Cross member ties can be custom made for various track widths.

Fisher 10 with newly designed tube track wheels.
Fisher 10 with skate board trays.

Peewee dolly.

G I track adapter is designed to connect both Filmair and Matthews straight or curved track. Two sets of stainless steel connectors and carrying case are included.


GI adapter used with GI track straight section and FilmAir curved section.
